Twenty vacuum tubes
Venti Vacuum Stutzmachine
Specially designed for conveyor belt systems or for individual installation. Popular with all young plant companies.
V003 with large Ton
Machine versions V003 with cuttings utilization(the cuttings are collected in the container bag)- high performance 3000 plants / hour- Pruning of potted plants and young plants in trays in one machine- quick easy adjustment speed control knife, conveyor belt vacuum and fan- consistent trimming quality
- cost-saving, quality-conscious pruning technology- Shoots are pushed upwards towards the center of the pot with air before pruning- different cutting systems can be used (fine cutting blades for young plants or blade bars for hard shoots)- existing commercially available conveyor belts can be used- all air flows can be electronically adjusted to the plants- Cutting height adjustable with handwheel crank- Frame mobileFrame dimensions: 1.9 mx 1.5 mx 2.1 m highAluminum frame weight: 150 kgbase frame hot-dip galvanized steelpneumatic tires 260Standard blade lengths: 40 cm or 50 cm
- cost-saving, quality-conscious pruning technology
V004 narrow version
Machine versions V004 with cuttings utilization
(the cuttings are collected in the container bag)- high performance 3000 plants / hour- Pruning of potted plants and young plants in trays in one machine- quick easy adjustment speed control knife, conveyor belt vacuum and fan- consistent trimming quality- cost-saving, quality-conscious pruning technology- Shoots are pushed upwards towards the center of the pot with air before pruning- different cutting systems can be used (fine cutting blades for young plants or blade bars for hard shoots)- existing commercially available conveyor belts can be used- all air flows can be electronically adjusted to the plants- Cutting height adjustable with handwheel crank- Frame mobileFrame dimensions: 2.2 mx 1 mx 2.2 m high
Aluminum frame weight: 150 kgbase frame hot-dip galvanized steelWheelbase for CC Container DimensionsStandard blade lengths: 40 cm
(the cuttings are collected in the container bag)
vENTI VACUUM
- Plants are sucked in with vacuum
void of wind
- Plant parts are collected in containers
